146 pci i/o cycles with data swap enable – Intel NETWORK PROCESSOR IXP2800 User Manual
Page 358

358
Hardware Reference Manual
Intel
®
IXP2800 Network Processor
PCI Unit
Table 146. PCI I/O Cycles with Data Swap Enable
Stepping
Description
A Stepping
A PCI IO cycle is treated like CSR where the data bytes are not swapped. It is sent in
the same byte order whether the PCI bus is configured in Big-Endian or Little-Endian
mode.
B Stepping
When PCI_CONTROL[IEE] is 0, PCI data is sent in the same byte order whether the
PCI bus is configured in Big-Endian or Little-Endian mode.
When PCI_CONTROL[IEE] is 1, PCI IO data will follow the same memory space
swapping rule. The address always follows the physical location, Example:
BEs not Swapped (1 byte access)
BEs Swapped (1 byte access)
ad[1:0]
BE3 BE2 BE1 BE0
ad[1:0]
BE3 BE2 BE1 BE0
0 0
1 1 1 0
1 1
0 1 1 1
0 1
1 1 0 1
1 0
1 0 1 1
1 0
1 0 1 1
0 1
1 1 0 1
1 1
0 1 1 1
0 0
1 1 1 0
BEs not Swapped (2 byte access)
BEs Swapped (2 byte access)
ad[1:0]
BE3 BE2 BE1 BE0
ad[1:0]
BE3 BE2 BE1 BE0
0 0
1 1 0 0
1 0
0 0 1 1
0 1
1 0 0 1
0 1
1 0 0 1
1 0
0 0 1 1
0 0
1 1 0 0
BEs not Swapped (3 byte access)
BEs Swapped (3 byte access)
ad[1:0]
BE3 BE2 BE1 BE0
ad[1:0]
BE3 BE2 BE1 BE0
0 0
1 0 0 0
0 1
0 0 0 1
0 1
0 0 0 1
0 0
1 0 0 0
BEs not Swapped (4 byte access)
BEs Swapped (4 byte access)
ad[1:0]
BE3 BE2 BE1 BE0
ad[1:0]
BE3 BE2 BE1 BE0
0 0
0 0 0 0
0 0
0 0 0 0
