Page 176
176
Hardware Reference Manual
Intel
®
IXP2800 Network Processor
Microengines
shows another sequence of instructions and the value of the various operands.
, shows the data in the registers for this example.
The value in Byte_Index[1:0] CSR (which controls the shift amount) for this example is 2.
As the examples show, byte aligning “n” words takes “n+1” cycles due to the first instruction
needed to start the operation.
Another mode of operation is to use the T_Index register with post-increment, to select the source
registers. T_Index operation is described later in this chapter.
4.3.2
CAM
is used to explain the CAM operation.
The CAM has 16 entries. Each entry stores a 32-bit value, which can be compared against a source
operand by instruction:
CAM_Lookup[dest_reg, source_reg]
.
All entries are compared in parallel, and the result of the lookup is a 9-bit value that is written into
the specified destination register in bits 11:3, with all other bits of the register set to 0 (the choice of
bits 11:3 is explained below). The result can also optionally be written into either of the LM_Addr
registers (see below in this section for details).
The 9-bit result consists of four State bits (dest_reg[11:8]), concatenated with a 1-bit Hit/Miss
indication (dest_reg[7]), concatenated with 4-bit entry number (dest_reg[6:3]). All other bits of
dest_reg are written with 0. Possible results of the lookup are:
•
miss (0) — lookup value is not in CAM, entry number is Least Recently Used entry (which
can be used as a suggested entry to replace), and State bits are 0000.
•
hit (1) — lookup value is in CAM, entry number is entry that has matched; State bits are the
value from the entry that has matched.
Table 60. Register Contents for Example 24
Register
Byte 3
[31:24]
Byte 2
[23:16]
Byte 1
[15:8]
Byte 0
[7:0]
0
3
2
1
0
1
7
6
5
4
2
B
A
9
8
3
F
E
D
C
Example 25. Little-Endian Align
Instruction
A Operand
B Operand
Prev A
Result
Byte_align_le[--, r0]
3210
--
--
--
Byte_align_le[dest1, r1]
7654
3210
3210
5432
Byte_align_le[dest2, r2]
BA98
7654
7654
9876
Byte_align_le[dest3, r3]
FEDC
BA98
BA98
DCBA
NOTE: B Operand comes from Prev_A register during byte_align_le instructions.
