shows the TBUF partition options. Note that the choice of element size is independent for
each partition.
The Microengine can write data from Microengine S_TRANSFER_OUT registers to the TBUF
using the
msf[write]
instruction, where they specify the starting byte number (which must be
aligned to four bytes), and number of 32-bit words to write. The number in the instruction can be
either the number of 32-bit words, or number of 32-bit word pairs, using the single and double
instruction modifiers, respectively. Data is pulled from the Microengine to TBUF via S_Pull_Bus.
msf[write, $s_xfer_reg, src_op_1, src_op_2, ref_cnt], optional_token
The
src_op_1
and
src_op_2
operands are added together to form the address in TBUF (note that
the base address of the TBUF is 0x2000). The
ref_cnt
operand is the number of 32-bit words or
word pairs, which are pulled from sequential S_TRANSFER_OUT registers, starting with
$s_xfer_reg
.
The Microengine can move data from DRAM to TBUF using the instruction
dram[tbuf_wr, --, src_op1, src_op2, ref_cnt], indirect_ref
The
src_op_1
and
src_op_2
operands are added together to form the address in DRAM, so the
dram instruction must use indirect mode to specify the TBUF address. The
ref_cnt
operand is the
number of 64-bit words that are written into TBUF.
Data is stored in big-endian order. The most significant (lowest numbered) byte of each 32-bit
word is transmitted first.
All elements within a TBUF partition are transmitted in the order. Control information associated
with the element (
) defines which bytes are valid. The data from the
TBUF will be shifted and byte-aligned to the TDAT pins as required. Four parameters are defined.
Prepend Offset — Number of the first byte to send. This is information that is prepended onto the
payload, for example as a header. It need not start at offset 0 in the element.
Prepend Length — Number of bytes of prepended information. This can be 0 to 31 bytes. If it is 0,
then the Prepend Offset must also be 0.
Table 97. Number of Elements per TBUF Partition
TBUF_Partition Field
TBUF_Element_Size_# Field
Partition Number
0
1
2
00 (1 partition)
00 (64 bytes)
128
Unused
Unused
01 (128 bytes)
64
10 (256 bytes)
32
01 (2 partitions)
00 (64 bytes)
96
32
Unused
01 (128 bytes)
48
16
10 (256 bytes
24
8
10 (3 partitions)
00 (64 bytes)
64
48
16
01 (128 bytes)
32
24
8
10 (256 bytes)
16
12
4
