DS33Z41 Quad IMUX Ethernet Mapper
93 of 167
Register Name: LI.TPPSR
Register Description: Transmit Packet Processor Status Register
Register Address: 0C8h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — — — — TEPF
Default 0 0 0 0 0 0 0 0
Bit 0: Transmit Errored Packet Insertion Finished (TEPF). This bit is set when the number of errored packets
indicated by the TPEN[7:0] bits in the TEPC register have been transmitted. This bit is cleared when errored
packet insertion is disabled, or a new errored packet insertion process is initiated.
Register Name:
LI.TPPSRL
Register Description: Transmit Packet Processor Status Register Latched
Register Address: 0C9h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — — — — TEPFL
Default — — — — — — — —
Bit 0: Transmit Errored Packet Insertion Finished Latched (TEPFL). This bit is set when the TEPF bit in the
TPPSR register transitions from zero to one.
Register Name:
LI.TPPSRIE
Register Description: Transmit Packet Processor Status Register Interrupt Enable
Register Address: 0CAh
Bit
# 7 6 5 4 3 2 1 0
Name — — — — — — — TEPFIE
Default 0 0 0 0 0 0 0 0
Bit 0: Transmit Errored Packet Insertion Finished Interrupt Enable (TEPFIE). This bit enables an interrupt if
the TEPFL bit in the LI.TPPSRL register is set.
0 = interrupt disabled
1 = interrupt enabled
