DS33Z41 Quad IMUX Ethernet Mapper
111 of 167
Register Name:
LI.TQHT
Register Description: Serial Interface Transmit Queue High Threshold (Watermark)
Register Address: 125h
Bit
# 7 6 5 4 3 2 1 0
Name TQHT7 TQHT6 TQHT5 TQHT4 TQHT3 TQHT2 TQHT1 TQHT0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Transmit Queue High Threshold (TQHT7 to TQTH0). The transmit queue high threshold for the
connection, in increments of 32 packets of 2048 bytes each. The value of this register is multiplied by 32 * 2048
bytes to determine the byte location of the threshold. Note that the transmit queue is for data that was received
from the Serial Interface to be sent to the Ethernet Interface.
Register Name:
LI.TQTIE
Register Description: Serial Interface Transmit Queue Cross Threshold Interrupt Enable
Register Address: 126h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — TFOVFIE TQOVFIE TQHTIE TQLTIE
Default 0 0 0 0 0 0 0 0
Bit 3: Transmit FIFO Overflow for Connection Interrupt Enable (TFOVFIE). If this bit is set, the watermark
interrupt is enabled for TFOVFLS.
Bit 2: Transmit Queue Overflow for Connection Interrupt Enable (TQOVFIE). If this bit is set, the watermark
interrupt is enabled for TQOVFLS.
Bit 1: Transmit Queue for Connection High Threshold Interrupt Enable (TQHTIE). If this bit is set, the
watermark interrupt is enabled for TQHTS.
Bit 0: Transmit Queue for Connection Low Threshold Interrupt Enable (TQLTIE). If this bit is set, the
watermark interrupt is enabled for TQLTS.
Register Name:
LI.TQCTLS
Register Description: Serial Interface Transmit Queue Cross Threshold Latched Status
Register Address: 127h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — TFOVFLS TQOVFLS TQHTLS TQLTLS
Default — — — — — — — —
Bit 3: Transmit Queue FIFO Overflowed Latched Status (TFOVFLS). This bit is set if the transmit queue FIFO
has overflowed. This register is cleared after a read. This FIFO is for data to be transmitted from the HDLC to be
sent to the SDRAM.
Bit 2: Transmit Queue Overflow Latched Status (TQOVFLS). This bit is set if the transmit queue has
overflowed. This register is cleared after a read.
Bit 1: Transmit Queue for Connection Exceeded High Threshold Latched Status (TQHTLS). This bit is set if
the transmit queue crosses the High Watermark. This register is cleared after a read.
Bit 0: Transmit Queue for Connection Exceeded Low Threshold Latched Status (TQLTLS). This bit is set if
the transmit queue crosses the Low Watermark. This register is cleared after a read.
