DS33Z41 Quad IMUX Ethernet Mapper
86 of 167
Register Name: BSRL
Register Description: BERT Status Register Latched
Register Address: 8Eh
Bit
# 7 6 5 4 3 2 1 0
Name — — — — PMSL BEL BECL OOSL
Default — — — — — — — —
Bit 3: Performance Monitor Update Status Latched (PMSL). This bit is set when the PMS bit transitions from 0
to 1.
Bit 2: Bit Error Detected Latched (BEL). This bit is set when a bit error is detected.
Bit 1: Bit Error Count Latched (BECL). This bit is set when the BEC bit transitions from 0 to 1.
Bit 0: Out Of Synchronization Latched (OOSL). This bit is set when the OOS bit changes state.
Register Name:
BSRIE
Register Description: BERT Status Register Interrupt Enable
Register Address: 90h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — PMSIE BEIE BECIE OOSIE
Default 0 0 0 0 0 0 0 0
Bit 3: Performance Monitoring Update Status Interrupt Enable (PMSIE). This bit enables an interrupt if the
PMSL bit is set.
0 = interrupt disabled
1 = interrupt enabled
Bit 2: Bit Error Interrupt Enable (BEIE). This bit enables an interrupt if the BEL bit is set.
0 = interrupt disabled
1 = interrupt enabled
Bit 1: Bit Error Count Interrupt Enable (BECIE). This bit enables an interrupt if the BECL bit is set.
0 = interrupt disabled
1 = interrupt enabled
Bit 0: Out Of Synchronization Interrupt Enable (OOSIE). This bit enables an interrupt if the OOSL bit is set.
0 = interrupt disabled
1 = interrupt enabled
