DS33Z41 Quad IMUX Ethernet Mapper
105 of 167
Register Name:
LI.RAPCB0
Register Description: Receive Aborted Packet Count Byte 0 Register
Register Address: 110h
Bit
# 7 6 5 4 3 2 1 0
Name RAPC7 RAPC6 RAPC5 RAPC4 RAPC3 RAPC2 RAPC1 RAPC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Packet Count (RAPC7 to RAPC0). Eight bits of a 24-bit value. Register
description below.
Register Name:
LI.RAPCB1
Register Description: Receive Aborted Packet Count Byte 1 Register
Register Address: 111h
Bit
# 7 6 5 4 3 2 1 0
Name RAPC15 RAPC14 RAPC13 RAPC12 RAPC11 RAPC10 RAPC9 RAPC8
Default 0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Packet Count (RAPC15 to RAPC8). Eight bits of a 24-bit value. Register
description below.
Register Name:
LI.RAPCB2
Register Description: Receive Aborted Packet Count Byte 2 Register
Register Address: 112h
Bit
# 7 6 5 4 3 2 1 0
Name RAPC23 RAPC22 RAPC21 RAPC20 RAPC19 RAPC18 RAPC17 RAPC16
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Packet Count (RAPC23 to RAPC16). The 24-bit value from these three registers
indicates the number of packets received with a packet abort indication. The byte count for these packets is
included in the receive aborted byte count register REBCR.
