DS33Z41 Quad IMUX Ethernet Mapper
107 of 167
Register Name: LI.RBC0
Register Description: Receive Byte Count 0 Register
Register Address: 118h
Bit # 7 6 5 4 3 2 1 0
Name RBC7 RBC6 RBC5 RBC4 RBC3 RBC2 RBC1 RBC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Byte Count (RBC7 to RBC0). Eight bits of a 32-bit value. Register description below.
Register Name: LI.RBC1
Register Description: Receive Byte Count 1 Register
Register Address: 119h
Bit # 7 6 5 4 3 2 1 0
Name RBC15 RBC14 RBC13 RBC12 RBC11 RBC10 RBC9 RBC8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Byte Count (RBC15 to RBC8). Eight bits of a 32-bit value. Register description below.
Register Name: LI.RBC2
Register Description: Receive Byte Count 2 Register
Register Address: 11Ah
Bit # 7 6 5 4 3 2 1 0
Name RBC23 RBC22 RBC21 RBC20 RBC19 RBC18 RBC17 RBC16
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Byte Count (RBC23 to RBC16). Eight bits of a 32-bit value. Register description below.
Register Name: LI.RBC3
Register Description: Receive Byte Count 3 Register
Register Address: 11Bh
Bit # 7 6 5 4 3 2 1 0
Name RBC31 RBC30 RBC29 RBC28 RBC27 RBC26 RBC25 RBC24
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Byte Count (RBC31 to RBC24). These 32 bits indicate the number of bytes contained in
packets stored in the receive FIFO without an abort indication. Note: Bytes discarded due to FCS extraction,
system loopback, FIFO reset, or an overflow condition may be included in this count.
