Register Name: GL.LIE
Register Description: Global Serial Interface Interrupt Enable
Register Address: 06h
Bit # 7 6 5 4 3 2 1 0
Name — — — LIN1TIE — — — LIN1RIE
Default 0 0 0 0 0 0 0 0
Bit 4: Serial Interface 1 Tx Interrupt Enable (LINE1TIE). Setting this bit to 1 enables an interrupt on LIN1TIS.
Bit 0: Serial Interface 1 Rx Interrupt Enable (LINE1RIE). Setting this bit to 1 enables an interrupt on LIN1RIS.
Register Name: GL.LIS
Register Description: Global Serial Interface Interrupt Status
Register Address: 07h
Bit # 7 6 5 4 3 2 1 0
Name - - - LIN1TIS - - - LIN1RIS
Default 0 0 0 0 0 0 0 0
Bit 4: Serial Interface 1 Tx Interrupt Status (LIN1TIS). This bit is set if Serial Interface 1 Transmit has an
enabled interrupt generating event. Serial Interface interrupts consist of HDLC interrupts and X.86 interrupts.
Bit 0: Serial Interface 1 Rx Interrupt Status (LIN1RIS). This bit is set if Serial Interface 1 Receive has an
enabled interrupt generating event. Serial Interface interrupts consist of HDLC interrupts and X.86 interrupts.
Register Name: GL.SIE
Register Description: Global Ethernet Interface Interrupt Enable
Register Address: 08h
Bit # 7 6 5 4 3 2 1 0
Name — — — — — — — SUB1IE
Default 0 0 0 0 0 0 0 0
Bit 0: Ethernet Interface 1 Interrupt Enable (SUB1IE). Setting this bit to 1 enables an interrupt on SUB1S.
Register Name: GL.SIS
Register Description: Global Ethernet Interface Interrupt Status
Register Address: 09h
Bit # 7 6 5 4 3 2 1 0
Name — — — — — — — SUB1IS
Default 0 0 0 0 0 0 0 0
Bit 0: Ethernet Interface 1 Interrupt Status (SUB1IS). This bit is set to 1 if Ethernet Interface 1 has an enabled
interrupt generating event. The Ethernet Interface consists of the MAC and The RMII/MII port.
