DS33Z41 Quad IMUX Ethernet Mapper
129 of 167
Register Name:
SU.MACFCR
Register Description: MAC Flow Control Register
Register Address: 001Ch (indirect)
001Ch:
Bit
# 31 30 29 28 27 26 25 24
Name PT15 PT14 PT13 PT12 PT11 PT10 PT09 PT08
Default
0 0 0 0 0 0 0 0
001Dh:
Bit
# 23 22 21 20 19 18 17 16
Name PT07 PT06 PT05 PT04 PT03 PT02 PT01 PT00
Default
0 1 0 1 0 0 0 0
001Eh:
Bit
# 15 14 13 12 11 10 09 08
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Default 0 0 0 0 0 0 0 0
001Fh:
Bit
# 07 06 05 04 03 02 01 00
Name Reserved Reserved Reserved Reserved Reserved Reserved FCE FCB
Default 0 0 0 0 0 0 1 0
Bits 31 to 16: Pause Time (PT15 to PT00). These bits are used for the Pause Time Field in transmitted Pause
Frames. This value is the number of time slots the remote node should wait prior to transmission.
Bit 1: Flow Control Enable (FCE) When set to 1, the MAC automatically detects pause frames and will disable
the transmitter for the requested pause time.
Bit 0: Flow Control Busy (FCB) The host can set this bit to 1 in order to initiate transmission of a pause frame.
During transmission of a pause frame, this bit remains set. The DS33Z41 will clear this bit when transmission of
the pause frame has been completed. The user should read this bit and ensure that this bit is equal to zero prior
to initiating a pause frame.
