DS33Z41 Quad IMUX Ethernet Mapper
113 of 167
Register Name:
SU.MACRD1
Register Description: MAC Read Data Byte 1
Register Address: 143h
Bit
# 7 6 5 4 3 2 1 0
Name MACRD15 MACRD14 MACRD13 MACRD12 MACRD11 MACRD10 MACRD9 MACRD8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: MAC Read Data Byte 1 (MACRD15 to MACRD8). One of four bytes of data read from the MAC.
Valid after a read command has been issued and the
SU.MACRWC .MCS bit is zero.
Register Name:
SU.MACRD2
Register Description: MAC Read Data Byte 2
Register Address: 144h
Bit #
7 6 5 4 3 2 1 0
Name MACRD23 MACRD22 MACRD21 MACRD20 MACRD19 MACRD18 MACRD17 MACRD16
Default 0 0 0 0 0 0 0 0
Bits 7 to 0: MAC Read Data Byte 2 (MACRD23 to MACRD16). One of four bytes of data read from the MAC.
Valid after a read command has been issued and the
SU.MACRWC .MCS bit is zero.
Register Name:
SU.MACRD3
Register Description: MAC Read Data Byte 3
Register Address: 145h
Bit
# 7 6 5 4 3 2 1 0
Name MACRD31 MACRD30 MACRD29 MACRD28 MACRD27 MACRD26 MACRD25 MACRD24
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: MAC Read Data Byte 3 (MACRD31 to MACRD24). One of four bytes of data read from the MAC.
Valid after a read command has been issued and the
SU.MACRWC .MCS bit is zero.
Register Name:
SU.MACWD0
Register Description: MAC Write Data Byte 0
Register Address: 146h
Bit
# 7 6 5 4 3 2 1 0
Name MACWD7 MACWD6 MACWD5 MACWD4 MACWD3 MACWD2 MACWD1 MACWD0
Default 0 0 0 0 0 0 0 0
Bits 7 to 0: MAC Write Data Byte 0 (MACWD7 to MACWD0). One of four bytes of data to be written to the
MAC. Data has been written after a write command has been issued and the
SU.MACRWC .MCS bit is zero.
