DS33Z41 Quad IMUX Ethernet Mapper
133 of 167
Register Name:
SU.RxFrmCtr
Register Description: MAC All Frames Received Counter
Register Address: 0200h (indirect)
0200h:
Bit
# 31 30 29 28 27 26 25 24
Name RXFRMC31 RXFRMC30 RXFRMC29 RXFRMC28 RXFRMC27 RXFRMC26 RXFRMC25 RXFRMC24
Default 0 0 0 0 0 0 0 0
0201h:
Bit
# 23 22 21 20 19 18 17 16
Name RXFRMC23 RXFRMC22 RXFRMC21 RXFRMC20 RXFRMC19 RXFRMC18 RXFRMC17 RXFRMC16
Default 0 0 0 0 0 0 0 0
0202h:
Bit
# 15 14 13 12 11 10 09 08
Name RXFRMC15 RXFRMC14 RXFRMC13 RXFRMC12 RXFRMC11 RXFRMC10 RXFRMC9 RXFRMC8
Default 0 0 0 0 0 0 0 0
0203h:
Bit
# 07 06 05 04 03 02 01 00
Name RXFRMC7 RXFRMC6 RXFRMC5 RXFRMC4 RXFRMC3 RXFRMC2 RXFRMC1 RXFRMC0
Default 0 0 0 0 0 0 0 0
Bits 31 to 0: All Frames Received Counter (RXFRMC31 to RXFRMC0). 32-bit value indicating the number of
frames received. Each time a frame is received, this counter is incremented by 1. This counter resets only upon
device reset, does not saturate, and rolls over to zero upon reaching the maximum value. The user should ensure
that the measurement period is less than the minimum length of time required for the counter to increment 2^32-1
times at the maximum frame rate. The user should store the value from the beginning of the measurement period
for later calculations, and take into account the possibility of a rollover occurring.
