DS33Z41 Quad IMUX Ethernet Mapper

135 of 167


Register Name:

SU.TxFrmCtr

Register Description:

MAC All Frames Transmitted Counter

Register Address:

0300h (indirect)


0300h:
Bit

# 31 30 29 28 27 26 25 24

Name

TXFRMC31 TXFRMC30 TXFRMC29 TXFRMC28 TXFRMC27 TXFRMC26 TXFRMC25 TXFRMC24

Default

0 0 0 0 0 0 0 0


0301h:
Bit

# 23 22 21 20 19 18 17 16

Name

TXFRMC23 TXFRMC22 TXFRMC21 TXFRMC20 TXFRMC19 TXFRMC18 TXFRMC17 TXFRMC16

Default

0 0 0 0 0 0 0 0


0302h:
Bit

# 15 14 13 12 11 10 09 08

Name

TXFRMC15 TXFRMC14 TXFRMC13 TXFRMC12 TXFRMC11 TXFRMC10 TXFRMC9 TXFRMC8

Default

0 0 0 0 0 0 0 0


0303h:
Bit

# 07 06 05 04 03 02 01 00

Name

TXFRMC7 TXFRMC6 TXFRMC5 TXFRMC4 TXFRMC3 TXFRMC2 TXFRMC1 TXFRMC0

Default

0 0 0 0 0 0

0 0

Bits 31 to 0: All Frames Transmitted Counter (TXFRMC31 to TXFRMC0). 32-bit value indicating the number of
frames transmitted. Each time a frame is transmitted, this counter is incremented by 1. This counter resets only
upon device reset, does not saturate, and rolls over to zero upon reaching the maximum value. The user should
ensure that the measurement period is less than the minimum length of time required for the counter to increment
2^32-1 times at the maximum frame rate. The user should store the value from the beginning of the measurement
period for later calculations, and take into account the possibility of a rollover occurring.
