DS33Z41 Quad IMUX Ethernet Mapper
136 of 167
Register Name:
SU.TxBytesCtr
Register Description: MAC All Bytes Transmitted Counter
Register Address: 0308h (indirect)
0308h:
Bit
# 31 30 29 28 27 26 25 24
Name TXBYTEC31 TXBYTEC30 TXBYTEC29 TXBYTEC28 TXBYTEC27 TXBYTEC26 TXBYTEC25 TXBYTEC24
Default 0 0 0 0 0 0 0 0
0309h:
Bit
# 23 22 21 20 19 18 17 16
Name TXBYTEC23 TXBYTEC22 TXBYTEC21 TXBYTEC20 TXBYTEC19 TXBYTEC18 TXBYTEC17 TXBYTEC16
Default 0 0 0 0 0 0 0 0
030Ah:
Bit
# 15 14 13 12 11 10 09 08
Name TXBYTEC15 TXBYTEC14 TXBYTEC13 TXBYTEC12 TXBYTEC11 TXBYTEC10 TXBYTEC9 TXBYTEC8
Default 0 0 0 0 0 0 0 0
030Bh:
Bit
# 07 06 05 04 03 02 01 00
Name TXBYTEC7 TXBYTEC6 TXBYTEC5 TXBYTEC4 TXBYTEC3 TXBYTEC2 TXBYTEC1 TXBYTEC0
Default 0 0 0 0 0 0 0 0
Bits 31 to 0: All Bytes Transmitted Counter (TXBYTEC31 to TXBYTEC0). 32-bit value indicating the number
of bytes transmitted. Each time a byte is transmitted, this counter is incremented by 1. This counter resets only
upon device reset, does not saturate, and rolls over to zero upon reaching the maximum value. The user should
ensure that the measurement period is less than the minimum length of time required for the counter to increment
2^32-1 times at the maximum data rate. The user should store the value from the beginning of the measurement
period for later calculations, and take into account the possibility of a rollover occurring.
