DS33Z41 Quad IMUX Ethernet Mapper

130 of 167

SU.MMCCTRL

MAC MMC Control Register

0100h (indirect)

0100h:
Bit

# 31 30 29 28 27 26 25 24

Name Reserved

Reserved

Default

0 0 0 0 0 0 0 0

0101h:
Bit

# 23 22 21 20 19 18 17 16

Name Reserved Reserved Reserved

Reserved Reserved Reserved Reserved Reserved

Default

0 0 0 0 0 0 0 0

0102h:
Bit

# 15 14 13 12 11 10 09 08

Name Reserved

Reserved

MXFRM10

MXFRM9 MXFRM8 MXFRM7 MXFRM6 MXFRM5

Default

0 0 1 0 1 1 1 1

0103h:
Bit

# 07 06 05 04 03 02 01 00

Name MXFRM4

MXFRM3

MXFRM2

MXFRM1

MXFRM0 Reserved Reserved Reserved

Default

0 1 1 1 0 0 1 0

Bits 13 to 3: Maximum Frame Size (MXFRM10 to MXFRM0). These bits indicate the maximum packet size
value. All transmitted frames larger than this value are counted as long frames.

Bit 1: Reserved. Note that this bit must be written to a “1” for proper operation.
