DS33Z41 Quad IMUX Ethernet Mapper

20 of 167

NAME PIN

TYPE

FUNCTION

POWER SUPPLIES

VDD3.3

G5–G10,

H2, H5,

H6,

H7–H10

I

VDD3.3: Connect to 3.3V Power Supply

VDD1.8

D3, D2,

E3, F4,

J4, K4,

L3, F10,

E11, E12,

D12, M13,

L12

I

VDD1.8: Connect to 1.8V Power Supply

VSS

A9, A12,

B10, C10,

D1, D5,

E7, E8,

F6, F8,

F12, F13,

J5, J6,

J11, J7,

J8, J9,

J10, K3,

K5, K7,
K8, K9,

K10, K12

I

VSS: Connect to the Common Supply Ground

N.C.

F5, F9, B8

—

No Connection. Do not connect these pins.
