DS33Z41 Quad IMUX Ethernet Mapper
61 of 167
9.1 Register
Bit
Maps
Table 9-2
,
Table 9-3
,
Table 9-4
,
Table 9-5
,
Table 9-6
, and
Table 9-7
contain the registers of the DS33Z41. Bits
that are reserved are noted with a single dash “-“. All registers not listed are reserved and should be initialized
with a value of 00h for proper operation, unless otherwise noted.
9.1.1 Global Register Bit Map
Table 9-2. Global Register Bit Map
A
DDR
Name B
IT
7 B
IT
6 B
IT
5 B
IT
4 B
IT
3 B
IT
2 B
IT
1 B
IT
0
000h
GL.IDRL
ID07 ID06 ID05 ID04 ID03 ID02 ID01 ID00
001h
GL.IDRH
ID15 ID14 ID13 ID12 ID11 ID10 ID09 ID08
002h
GL.CR1
- - - - -
REF_CLKO
INTM
RST
003h
GL.BLR
- - - - - - -
GL.BLC1
004h
GL.RTCAL
- - -
RLCALS1
- - -
TLCALS1
005h
GL.SRCALS
- - - - - -
REFCLKS
SYSCLS
006h
GL.LIE
- - -
LIN1TIE
- - -
LIN1RIE
007h
GL.LIS
- - -
LIN1TIS
- - -
LIN1RIS
008h
GL.SIE
- - - - - - -
SUB1IE
009h
GL.SIS
- - - - - - -
SUB1IS
00Ah
GL.TRQIE
- - -
TQ1IE
- - -
RQ1IE
00Bh
GL.TRQIS
- - -
TQ1IS
- - -
RQ1IS
00Ch
GL.IBIE
- - - - - -
IMUXIE
BIE
00Dh
GL.IBIS
- - - - - - IIS
BIS
00Eh
GL.CON1
- - - - - - -
LINE1[0]
012h
GL.C1QPR
- - - -
C1MRPRR
C1HWPRR
C1MHPR
C1HRPR
016h
GL.IMXCN
- T1E1
RXE
SENDE
L4 L3 L2 L1
017h
GL.IMXC
IMUXC7 IMUXC6 IMUXC5 IMUXC4 IMUXC3 IMUXC2 IMUXC1 IMUXC0
018h
GL.IMXSS
ITSYNC4 ITSYNC3 ITSYNC2 ITSYNC1 IRSYNC4 IRSYNC3 IRSYNC2 IRSYNC1
019h
GL.IMXSIE
ITSYNCIE4 ITSYNCIE3 ITSYNCIE2 ITSYNCIE1 IRSYNCIE4 IRSYNCIE3 IRSYNCIE2 IRSYNCIE1
01Ah
GL.IMXSLS
ITSYNCLS4 ITSYNCLS3 ITSYNCLS2 ITSYNCLS1 IRSYNCLS4 IRSYNCLS3 IRSYNCLS2 IRSYNCLS1
01Bh
GL.IMXDFD
IMUXDFD7 IMUXDFD6 IMUXDFD5 IMUXDFD4 IMUXDFD3 IMUXDFD2 IMUXDFD1 IMUXDFD0
01Ch
GL.IMXDFEIE
- - - - - - -
IDDEIE0
01Dh
GL.IMXDFDELS
- - - - - - -
IDDELS0
01Eh
GL.IMXOOFIE
TOOFIE4
TOOFIE3
TOOFIE2
TOOFIE1
ROOFIE4
ROOFIE3
ROOFIE2
ROOFIE1
01Fh
GL.IMXOOFLS
TOOFLS4 TOOFLS3 TOOFLS2 TOOFLS1 ROOFL4 ROOFL3 ROOFLS2 ROOFLS1
020h
GL.BISTEN
- - - - - - -
BISTE
021h
GL.BISTPF
- - - - - -
BISTDN
BISTPF
03Ah
GL.SDMODE1
- - - -
WT
BL2
BL1
BL0
03Bh
GL.SDMODE2
- - - - -
LTMOD2
LTMOD1
LTMOD0
03Ch
GL.SDMODEWS
- - - - - - -
SDMW
03Dh
GL.SDRFTC
SREFT7 SREFT6 SREFT5 SREFT4 SREFT3 SREFT2 SREFT1 SREFT0
Note: All address locations not listed are reserved.
