DS33Z41 Quad IMUX Ethernet Mapper

27 of 167

8.3 Resets and Low-Power Modes

The external

RST pin and the global reset bit in

GL.CR1

create an internal global reset signal. The global reset

signal resets the status and control registers on the chip (except the

GL.CR1.

RST bit) to their default values and

resets all the other flops to their reset values. The device should be reset after all power supplies, SYSCLKI,
RX_CLK, and TX_CLK are stable. The processor bus output signals are also placed in high-impedance mode
when the

RST pin is active (low). The global reset bit (

GL.CR1.

RST) stays set after a one is written to it, but is

reset to zero when the external

RST pin is active or when a zero is written to it. Allow 5ms after initiating a reset

condition for the reset operation to complete.

The Serial Interface reset bit in

LI.RSTPD

resets all the status and control registers on the Serial Interface to their

default values, except for the

LI.RSTPD.

RST bit. The Serial Interface includes the HDLC encoder/decoder, X86

encoder and decoder and the corresponding serial port. The Serial Interface reset bit (

LI.RSTPD.

RST) stays set

after a one is written to it, but is reset to zero when the global reset signal is active or when a zero is written to it.

Table 8-2. Reset Functions

RESET FUNCTION

LOCATION

COMMENTS

Hardware Device Reset

RST Pin

Transition to a logic 0 level resets the
device.

Hardware JTAG Reset

JTRST Pin

Resets the JTAG test port.

Global Software Reset

GL.CR1

Writing to this bit resets the device.

Serial interface Reset

LI.RSTPD

Writing to this bit resets a Serial
Interface.

Queue Pointer Reset

GL.C1QPR

Writing to this bit resets the Queue
Pointers.

There are several features in the DS33Z41 to reduce power consumption. The reset bit in the

LI.RSTPD

register

minimizes power usage in the Serial Interface. Additionally, the

RST pin or

GL.CR1

.RST bit may be held in reset

indefinitely to keep the device in a low-power mode. Note that exiting a reset condition requires re-initialization
and configuration. For the lowest possible standby current, clocks may be externally gated.
