DS33Z41 Quad IMUX Ethernet Mapper
64 of 167
A DDR N AME B IT 7 B IT 6 B IT 5 B IT 4 B IT 3 B IT 2 B IT 1 B IT 0
103h
LI.RMPSCH RMX15 RMX14 RMX13 RMX12 RMX11 RMX10 RMX9 RMX8
104h
LI.RPPSR - - - - - REPC RAPC RSPC
105h
LI.RPPSRL REPL RAPL RIPDL RSPDL RLPDL REPCL RAPCL RSPCL
106h
LI.RPPSRIE REPIE RAPIE RIPDIE RSPDIE RLPDIE REPCIE RAPCIE RSPCIE
107h Reserved
108h
LI.RPCB0 RPC7 RPC6 RPC5 RPC4 RPC3 RPC2 RPC1 RPC0
109h
LI.RPCB1 RPC15 RPC14 RPC13 RPC12 RPC11 RPC10 RPC09 RPC08
10Ah
LI.RPCB2 RPC23 RPC22 RPC21 RPC20 RPC19 RPC18 RPC17 RPC16
10Ch
LI.RFPCB0 RFPC7 RFPC6 RFPC5 RFPC4 RFPC3 RFPC2 RFPC1 RFPC0
10Dh
LI.RFPCB1 RFPC15 RFPC14 RFPC13 RFPC12 RFPC11 RFPC10 RFPC9 RFPC8
10Eh
LI.RFPCB2 RFPC23 RFPC22 RFPC21 RFPC20 RFPC19 RFPC18 RFPC17 RFPC16
10Fh Reserved
110h
LI.RAPCB0 RAPC7 RAPC6 RAPC5 RAPC4 RAPC3 RAPC2 RAPC1 RAPC0
111h
LI.RAPCB1 RAPC15 RAPC14 RAPC13 RAPC12 RAPC11 RAPC10 RAPC9 RAPC8
112h
LI.RAPCB2 RAPC23 RAPC22 RAPC21 RAPC20 RAPC19 RAPC18 RAPC17 RAPC16
113h Reserved
- - - - - - - -
114h
LI.RSPCB0 RSPC7 RSPC6 RSPC5 RSPC4 RSPC3 RSPC2 RSPC1 RSPC0
115h
LI.RSPCB1 RSPC15 RSPC14 RSPC13 RSPC12 RSPC11 RSPC10 RSPC9 RSPC8
116h
LI.RSPCB2 RSPC23 RSPC22 RSPC21 RSPC20 RSPC19 RSPC18 RSPC17 RSPC16
118h
LI.RBC0 RBC7 RBC6 RBC5 RBC4 RBC3 RBC2 RBC1 RBC0
119h
LI.RBC1 RBC15 RBC14 RBC13 RBC12 RBC11 RBC10 RBC9 RBC8
11Ah
LI.RBC2 RBC23 RBC22 RBC21 RBC20 RBC19 RBC18 RBC17 RBC16
11Bh
LI.RBC3 RBC31 RBC30 RBC29 RBC28 RBC27 RBC26 RBC25 RBC24
11Ch
LI.RAC0 REBC7 REBC6 REBC5 REBC4 REBC3 REBC2 REBC1 REBC0
11Dh
LI.RAC1 REBC15 REBC14 REBC13 REBC12 REBC11 REBC10 REBC9 REBC8
11Eh
LI.RAC2 REBC23 REBC22 REBC21 REBC20 REBC19 REBC18 REBC17 REBC16
11Fh
LI.RAC3 REBC31 REBC30 REBC29 REBC28 REBC27 REBC26 REBC25 REBC24
120h
LI.RHPMUU - - - - - - - RPMUU
121h
LI.RHPMUS - - - - - - - RPMUUS
122h
LI.RX86S - - - - SAPIHNE SAPILNE CNE ANE
123h
LI.RX86LSIE - - - - SAPINE01IM SAPINEFEIM CNE3LIM ANE4IM
124h
LI.TQLT TQLT7 TQLT6 TQLT5 TQLT4 TQLT3 TQLT2 TQLT1 TQLT0
125h
LI.TQHT TQHT7 TQHT6 TQHT5 TQHT4 TQHT3 TQHT2 TQHT1 TQHT0
126h
LI.TQTIE - - - - TFOVFIE TQOVFIE TQHTIE TQLTIE
127h
LI.TQCTLS - - - - TFOVFLS TQOVFLS TQHTLS TQLTLS
Note: 0DEh–0FFh, 128h–13Fh are reserved.
