DS33Z41 Quad IMUX Ethernet Mapper
110 of 167
Register Name:
LI.RX86LSIE
Register Description: Receive X.86 Interrupt Enable
Register Address: 123h
Bit
# 7 6 5 4 3 2 1 0
Name — — — — SAPINE01IM SAPINEFEIM CNE3LIM ANE4IM
Default 0 0 0 0 0 0 0 0
Bit 3: SAPI Octet Not Equal to LI.TRX86SAPIH Interrupt Enable (SAPINE01IM). If this bit is set to 1,
LI.RX86S.SAPIHNE will generate an interrupt.
Bit 2: SAPI Octet Not Equal to LI.TRX86SAPIL Interrupt Enable (SAPINEFEIM). If this bit is set to 1,
LI.RX86S.SAPILNE will generate an interrupt.
Bit 1: Control Not Equal to LI.TRX8C Interrupt Enable (CNE3LIM). If this bit is set to 1, LI.RX86S.CNE will
generate an interrupt.
Bit 0: Address Not Equal to LI.TRX86A Interrupt Enable (ANE4IM). If this bit is set to 1, LI.RX86S.ANE will
generate an interrupt.
Register Name: LI.TQLT
Register Description: Serial Interface Transmit Queue Low Threshold (Watermark)
Register Address: 124h
Bit # 7 6 5 4 3 2 1 0
Name TQLT7 TQLT6 TQLT5 TQLT4 TQLT3 TQLT2 TQLT1 TQLT0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Transmit Queue Low Threshold (TQLT7 to TQLT0). The transmit queue low threshold for the
connection, in increments of 32 packets of 2048 bytes each. The value of this register is multiplied by 32 * 2048
bytes to determine the byte location of the threshold. Note that the transmit queue is for data that was received
from the Serial Interface to be sent to the Ethernet Interface.
