DS33Z41 Quad IMUX Ethernet Mapper
108 of 167
Register Name: LI.RAC0
Register Description: Receive Aborted Byte Count 0 Register
Register Address: 11Ch
Bit # 7 6 5 4 3 2 1 0
Name REBC7 REBC6 REBC5 REBC4 REBC3 REBC2 REBC1 REBC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Byte Count (RBC7 to RBC0). Eight bits of a 32-bit value. Register description
below.
Register Name: LI.RAC1
Register Description: Receive Aborted Byte Count 1 Register
Register Address: 11Dh
Bit # 7 6 5 4 3 2 1 0
Name REBC15 REBC14 REBC13 REBC12 REBC11 REBC10 REBC9 REBC8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Byte Count (RBC15 to RBC8). Eight bits of a 32-bit value. Register description
below.
Register Name: LI.RAC2
Register Description: Receive Aborted Byte Count 2 Register
Register Address: 11Eh
Bit # 7 6 5 4 3 2 1 0
Name REBC23 REBC22 REBC21 REBC20 REBC19 REBC18 REBC17 REBC16
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Byte Count (RBC16 to RBC23). Eight bits of a 32-bit value. Register description
below.
Register Name: LI.RAC3
Register Description: Receive Aborted Byte Count 3 Register
Register Address: 11Fh
Bit # 7 6 5 4 3 2 1 0
Name REBC31 REBC30 REBC29 REBC28 REBC27 REBC26 REBC25 REBC24
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Receive Aborted Byte Count (REBC31 to REBC24). These 32 bits indicate the number of bytes
contained in packets stored in the receive FIFO with an abort indication. Note: Bytes discarded due to FCS
extraction, system loopback, FIFO reset, or an overflow condition may be included in this count.
