4-2 WebBIOS Configuration Utility
Version 2.0 Copyright © 2003–2006 by LSI Logic Corporation. All rights reserved.
•
Displays the physical properties of devices
•
Allows capacity expansion and drive migration
The WebBIOS CU provides a configuration wizard to guide you through
the configuration of logical drives and physical arrays.
4.2 Quick Configuration Steps
This section provides the steps to configure arrays and logical drives
using the WebBIOS CU. The following sections describe how to perform
each action using the WebBIOS CU. The steps are:
Step 1. Power-on the system.
Step 2. Start the WebBIOS CU by pressing CTRL+H.
Step 3. Start the Configuration Wizard.
Step 4. Select a configuration method.
Step 5. Create arrays using the available physical drives.
Step 6. Define the logical drive(s) using the space in the arrays.
Step 7. Initialize the new logical drives.
4.3 Starting the WebBIOS Configuration Utility on the
Host Computer
While the host computer boots, hold down the CTRL key and press the
H key when the following appears:
Copyright© LSI Logic Corporation
Press to Run Configuration Utility
Or press for WebBIOS
After you press CTRL+H, the Adapter Selection screen displays, as
shown in
Figure 4.1 . This screen lists the adapters, adapter numbers,
and firmware versions. Select an adapter and press the Start button to
begin the configuration.
