Configuration Utility Menu 3-13
Version 2.0 Copyright © 2003–2006 by LSI Logic Corporation. All rights reserved.
3.3.3.6 Channel Submenu Description
Select this option from the Configuration Utility Objects menu to choose
a channel or port on the controller.
Table 3.7 lists and describes the
Channel submenu options.
Table 3.6 Configuration Utility Physical Drive Submenu
Option Description
Rebuild Use this option to rebuild a failed physical drive that is part of a redundant
array. Data from a good drive or drives rebuilds the failed drive.
Clear Use this option to clear the data from SCSI disk drives. This is for SCSI
drives only.
Force Online Use this option to change the state of the selected disk drive to Online.
Force Offline/
Remove HSP Use this option to change the state of the selected disk drive to Fail.
Make Hot Spare Use this option to designate the selected disk drive as a hot spare. A hot
spare is an idle, powered-on standby drive ready for use if another drive fails.
When a drive fails, the controller firmware automatically rebuilds the data on
the hot spare from a redundant drive or drives. Data can be rebuilt only from
logical drives with redundancy (RAID 1, 5, 10, and 50, not RAID 0). The hot
spare must be at least as large as the failed drive it is replacing.
View Drive Information Use this option to display the drive properties for the selected physical
device, such as device type, capacity, vendor ID, and device errors.
View Rebuild Progress Use this option to enable synchronous negotiation with a physical device.
This is available only for SCSI controllers.
View Rebuild Progress Use this option to view the progress of the physical drive rebuild.
SCSI Command
Qtagging Use this option to set the number of queue tags per command to Disabled,
2, 3, 4, or Enhanced. The default setting is Enhanced. This option is
available for SCSI controllers only.
Transfer Speed Option Use this option to set the data transfer speed.
Table 3.7 Configuration Utility Channel Submenu
Option Description
Termination State Use this option to control termination on the MegaRAID SCSI controller. The
MegaRAID SCSI controller sets this option automatically, though you can set
it manually.
SCSI Transfer Rate This option enables the user to set the SCSI transfer rate as Fast, Ultra, Ultra2,
Ultra160, or Ultra320 SCSI.
