3-2
BIOS Configuration Utility and MegaRAID Manager
Version 2.0
Copyright © 2003–2006 by LSI Logic Corporation. All rights reserved.
•
Reconstruct logical drives after changing RAID levels or adding a
hard drive to an array
•
Select a MegaRAID host adapter
This chapter consists of the following sections:
•
Section 3.1, “Quick Configuration Steps for the BIOS
Configuration Utility”
•
Section 3.2, “Quick Configuration Steps for MegaRAID Manager”
•
Section 3.3, “Configuration Utility Menu”
•
Section 3.4, “Detailed Configuration Instructions”
•
Section 3.5, “Deleting Logical Drives”
•
Section 3.6, “Performing Drive Roaming”
•
Section 3.7, “Performing Drive Migration”
•
Section 3.8, “Rebuilding Failed Disks”
•
Section 3.9, “FlexRAID Virtual Sizing,”
•
Section 3.10, “Checking Data Consistency”
•
Section 3.11, “Reconstructing Logical Drives”
•
Section 3.12, “Replacing a Failed Controller Containing Data in
the TBBU”
•
Section 3.13, “Using a Preloaded System Drive”
•
Section 3.14, “Exiting MegaRAID Configuration Utility”
3.1
Quick Configuration Steps for the BIOS Configuration Utility
This section provides quick installation steps for users who are familiar
with the MegaRAID utilities and tools. Refer to
Configuration Instructions,” on page 3-16
for detailed configuration
instructions. To configure arrays and logical drives using the
MegaRAID CU:
Step 1.
Boot the system.
Step 2.
Start the MegaRAID CU by pressing CTRL+M.
