3-30 BIOS Configuration Utility and MegaRAID Manager
Version 2.0 Copyright © 2003–2006 by LSI Logic Corporation. All rights reserved.
Note: The default for SCSI termination is onboard SCSI termination
enabled. See the MegaRAID 320 Storage Adapters User’s
Guide for more information of SCSI termination.
Step 7. Perform a safety check.
◊
Make sure all cables are properly attached.
◊
Make sure the RAID controller is properly installed.
◊
Close the cabinet of the host system.
◊
Turn power on after completing the safety check.
Step 8. Power on the system.
The controller then detects the RAID configuration from the
configuration data on the drives.
3.8 Rebuilding Failed Disks
If hot spare disks are present in the system, the MegaRAID controller
automatically uses them to rebuild failed disks.
3.8.1 Rebuild Types
Table 3.12 describes automatic and manual rebuilds.
Table 3.12 Rebuild Types
Type Description
Automatic
Rebuild If you have configured hot spares, the RAID controller automatically tries to use them to
rebuild failed disks. Select Objects
→
Physical Drive to display the list of physical drives
while a rebuild is in progress. The hot spare drive changes to REBLD A[array number]-
[drive number], indicating the hard drive is being replaced by the hot spare. For example,
REBLD A01-02 indicates that the data is being rebuilt in array 1 on hard drive 2.
Manual
Rebuild Manual rebuild is necessary if no hot spares with enough capacity to rebuild the failed
drives are available.You must insert a drive with enough storage into the subsystem
before rebuilding the failed drive.
The CU allows manual rebuild for an individual drive or a group of drives. Rebuilding a
group of drives is done through the batch mode. Use the following procedures to rebuild
a failed drive manually in individual or batch mode.
