Configuration Utility Menu 3-7
Version 2.0 Copyright © 2003–2006 by LSI Logic Corporation. All rights reserved.
Table 3.3 Configuration Utility Adapter Submenu
Option Description
Clear Configuration This option erases the current RAID configuration in the NVRAM.
FlexRAID PowerFail Use this option to enable the FlexRAID
®
PowerFail feature, which allows drive
reconstruction to continue when the system restarts after a power failure.
Fast Initialization Use this option to initialize the logical drive by writing zeros to the first sector of
the logical drive. The fast initialization completes in 3 seconds.
When this option is set to Disabled, a full initialization takes place on the entire
logical drive. On a larger array (over five drives), LSI recommends setting fast
initialization to Disabled, then initializing. Otherwise, the controller runs a
background consistency check within 5 minutes of reboot or RAID 5 creation.
Disk Spin up Timings Use this option to configure the timing for spinning up the hard disk drives. The
options are Automatic , 2 disks every 6 secs , 4 disks every 6 secs , and
6 disks every 6 secs .
Cache Flush Timings Use this option to set the cache flush interval to 2, 4, 6, 8, or 10 seconds.
Rebuild Rate Use this option to change the drive rebuild rate. The rebuild rate is the
percentage of system resources dedicated to rebuilding a failed drive. A rebuild
rate of 100 percent means the system is totally dedicated to rebuilding the failed
drive. The default is 30 percent.
Other Adapter
Information Use this option to display general information about the adapter, such as the
adapter type, firmware version, BIOS version, and DRAM size.
Factory Default Use this option to load the default MegaRAID Configuration Utility settings.
Disable BIOS Use this option to disable the BIOS.
Emulation Use this option to select the I
2
C or mass storage mode. The default is mass
storage mode.
Auto Rebuild Use this option to enable automatic drive rebuilds after a drive failure. The failed
drive is rebuilt with data from another drive or drives.
Initiator ID Use this option to set the initiator ID for the adapter. The default is 7.
Boot Time BIOS
Options The following are options you can select for events that occur during bootup,
such as BIOS error or messages.
•
BIOS Stops on Error: Select this option to have the system BIOS stop during
bootup if there are BIOS errors. This gives you the option to enter the
configuration utility to resolve the problem.
•
BIOS Echoes Messages: When set to On (the default), all controller BIOS
messages display during bootup.
•
BIOS Configuration Autoselection: Use this option if there is a mismatch
between configuration data in the hard disk drives and NVRAM, so you can
select a method to resolve it. The options are
Disk and User . The default
is User .
