Chapter 6
User Setup Screens
Setup screens are available to the user for customizing display and some mea-
surement parameters. The specific screens that are avialable are often deter-
mined for each system by the OEM or by the supervisor responsible for system
setup and maintenance. A collection of setup screens typically made available to
the user is included in this chapter. Screens presented in this chapter are listed
below:
Setup task Screen Page
Setting up axis encoders Encoder set up program .......................... 6-2
Tools/Customize Screens
Customizing screen colors Tools/Customize/Colors ......................... 6-6
Including a startup message Tools/Customize/Miscellaneous ............. 6-14
Specifying error messages Tools/Customize/Errors .......................... 6-15
Specifying status bar information Tools/Customize/Status bar .................... 6-17
Specifying toolbar contents Tools/Customize/Toolbars ...................... 6-18
Tools/Options Screens
Setting up video parameters Tools/Options/VED ................................ 6-23
Setting up touch probe parameters Tools/Options/Probes ............................. 6-36
Setting up programming parameters Tools/Options/Programming .................. 6-39
Specifying the number of program executions Tools/Options/Runs ................................ 6-45
Selecting system sounds Tools/Options/Sounds ............................ 6-46
Locking display and set up settings Tools/Options/Locks .............................. 6-47
Specifying measurement parameters Tool/Options/Measure ............................ 6-49
Specifying displays of parts and probes Tools/Options/Part view ......................... 6-53
Assigning functions to joystick and foot switch buttons Tools/Options/Buttons ............................ 6-63
Specifying display resolution and formatting time/date Tools/Options/Display ............................ 6-67
Specifying encoder resolution Tools/Options/Encoder ........................... 6-69
Specifying system file locations Tools/Options/Files ................................ 6-71
Saving user settings and configuring general parameters Tools/Options/General ............................ 6-74
Tools/CNC/Screens
Setting up the joystick Tools/CNC/Joystick ............................... 6-79
Setting up the motion mouse Tools/CNC/Motion mouse ...................... 6-83
Setting up and calibrating a probe rack Tools/CNC/Probe rack ........................... 6-86
6 - 1
