186 Programming: Tools
5.2 T
ool data
Calling tool data
A TOOL CALL block in the part program is defined with the following
data:
 Select the tool call function with the TOOL CALL key
 Tool number: Enter the number or name of the tool.
The tool must already be defined in a G99 block or in
the tool table. Press the TOOL NAME soft key to
enter the name. The TNC automatically places the
tool name in quotation marks. The tool name always
refers to the entry in the active tool table TOOL.T. If
you wish to call a tool with other compensation
values, also enter the index you defined in the tool
table after the decimal point. There is a SELECT soft
key for calling a window from which you can select a
tool defined in the tool table TOOL.T directly without
having to enter the number or name: See also "Editing
tool data in the selection window" on page 187.
 Working spindle axis X/Y/Z : Enter the tool axis
 Spindle speed S : Enter the spindle speed directly or
allow the TNC to calculate the spindle speed if you are
working with cutting data tables. Press the
S CALCULATE AUTOMAT. soft key. The TNC limits
the spindle speed to the maximum value set in MP
3515. Alternatively, you can define the cutting speed
Vc in m/min. Press the VC soft key
 Feed rate F
: Enter the feed rate directly or allow the
TNC to calculate the feed rate if you are working with
cutting data tables. Press the F CALCULATE
AUTOMAT. soft key. The TNC limits the feed rate to
the maximum feed rate of the slowest axis (set in
MP1010). F is effective until you program a new feed
rate in a positioning or TOOL CALL block.
 Tool length oversize DL
: Enter the delta value for the
tool length
 Tool radius oversize DR : Enter the delta value for the
tool radius
 Tool radius oversize DR2 : Enter the delta value for
the tool radius 2
