Technical Information 21.3
21
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
505
User functions
■
Context-sensitive help function for error messages
■
Graphic support for the programming of cycles
■
Comment blocks in the NC program
Teach-In
■
Actual positions can be transferred directly into the NC program
■
Graphic simulation before program run, even while another program is
being run Test run graphics
Display modes
■
Plan view / projection in 3 planes / 3-D view
■
Magnification of details
Programming graphics
■
In the
Programming mode, the contour of the NC blocks is drawn on
screen while they are being entered (2-D pencil-trace graphics), even
while another program is running
Program-run graphics
Display modes
■
Graphic simulation of real-time machining in plan view / projection in 3
planes / 3-D view
Machining time
■
Calculation of machining time in the
Test Run operating mode
■
Display of the current machining time in the
Program Run, Single
Block and Program Run, Full Sequence operating modes
Returning to the contour
■
Mid-program startup in any block in the program, returning the tool to
the calculated nominal position to continue machining
■
Program interruption, contour departure and return
Datum tables
■
Multiple datum tables, for storing workpiece-related datums
■
Calibrate the touch probe Touch probe cycles
■
Datum setting, manual
■
Automatic tool measurement
