Tool compensation 5.3
5
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
165
Entering radius compensation
Radius compensation is entered in a positioning block. Enter the
coordinates of the target point and confirm your entry with ENT
TOOL RADIUS COMP: R+/R–/NO COMP?
The TNC extends the traverse path of the tool by
the tool radius
The TNC shortens the traverse path of the tool by
the tool radius
Select tool movement without radius
compensation or cancel radius compensation:
Press the ENT key
Terminate the block: Press the END key
