Ethernet interface rj45 socket – HEIDENHAIN TNC 128 (77184x-02) User Manual
Page 503
Connector pin layout and connection cables for data interfaces
21.2
21
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
503
Ethernet interface RJ45 socket
Maximum cable length:
Unshielded: 100 m
Shielded: 400 m
Pin
Signal
Description
1
TX+
Transmit Data
2
TX–
Transmit Data
3
REC+
Receive Data
4
Vacant
5
Vacant
6
REC–
Receive Data
7
Vacant
8
Vacant
