Magnification or reduction of details
You can select the graphics display
Shift the soft-key row (second row, see figure)
The following functions are available:
Function
Soft key
Press and hold the desired soft key to move
the frame overlay
Press the soft key to reduce the detail
Press the soft key to enlarge the detail
The
RESET WORKPIECE BLANK soft key is used to restore the
original section.
