Tool table: Tool data required for automatic tool measurement
Abbr. Inputs Dialog
CUT
Number of teeth (99 teeth maximum)
Number of teeth?
LTOL Permissible deviation from tool length L for wear
detection. If the entered value is exceeded, the TNC
locks the tool (status
L). Input range: 0 to 0.9999 mm
Wear tolerance: length?
RTOL Permissible deviation from tool radius R for wear
detection. If the entered value is exceeded, the TNC
locks the tool (status
L). Input range: 0 to 0.9999 mm
Wear tolerance: radius?
R2TOL Permissible deviation from tool radius R2 for wear
detection. If the entered value is exceeded, the TNC
locks the tool (status
L). Input range: 0 to 0.9999 mm
Wear tolerance: Radius 2?
DIRECT.
Cutting direction of the tool for measuring the tool during
rotation
Cutting direction (M3 = –)?
R_OFFS
Tool radius measurement: Tool offset between stylus
center and tool center. Default setting: No value entered
(offset = tool radius)
Tool offset: radius?
L_OFFS Tool length measurement: Tool offset in addition to
offsetToolAxis between upper surface of stylus and
lower surface of tool. Default: 0
Tool offset: length?
LBREAK
Permissible deviation from tool length
L for breakage
detection. If the entered value is exceeded, the TNC
locks the tool (status
L). Input range: 0 to 3.2767 mm
Breakage tolerance: length?
RBREAK Permissible deviation from tool radius R for breakage
detection. If the entered value is exceeded, the TNC
locks the tool (status
L). Input range: 0 to 0.9999 mm
Breakage tolerance: radius?
