Tables and overviews
21.3 Technical Information
21
504
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
21.3 Technical Information
Technical Information
Explanation of symbols
■
Standard
□
Axis option
1 Software option 1
User functions
■
Basic version: 3 axes plus closed-loop spindle Brief description
□
1st additional axis for 4 axes plus closed-loop spindle
□
2nd additional axis for 5 axes plus closed-loop spindle
Program entry In HEIDENHAIN conversational
■
Nominal positions for lines in Cartesian coordinates Position entry
■
Incremental or absolute dimensions
■
Display and entry in mm or inches
Tool compensation
■
Tool radius in the working plane and tool length
Tool tables Multiple tool tables with any number of tools
Parallel operation Creating a program with graphical support while another program is being
run
■
Subprograms Program jumps
■
Program-section repeat
■
Any desired program as subroutine
■
Cycles for drilling, and conventional and rigid tapping
■
Roughing and finishing rectangular pockets
■
Cycles for pecking, reaming, boring, and counterboring
■
Roughing and finishing rectangular studs
Fixed cycles
■
Cartesian and polar point patterns
■
OEM cycles (special cycles developed by the machine tool builder) can
also be integrated
■
Datum shift, mirroring Coordinate transformation
■
Scaling factor (axis-specific)
■
Mathematical functions =, +, –, *, /, roots
■
Logical operations (=,
�, <, >)
■
Calculating with parentheses
■
sin
α, cos α, tan α , arc sin, arc cos, arc tan, a
n , e n , In, log, absolute
value of a number, constant
π, negation, truncation of digits before or
after the decimal point
Q parameters
Programming with variables
■
Functions for calculation of circles
■
String parameters
■
Calculator Programming aids
■
Complete list of all current error messages
