Tool data 5.2
5
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
151
Tool table: Standard tool data
Abbr. Inputs Dialog
T
Number by which the tool is called in the program (e.g.
5, indexed: 5.2) -
NAME
Name by which the tool is called in the program (no
more than 32 characters, all capitals, no spaces)
Tool name?
L Compensation value for tool length L Tool length?
R Compensation value for the tool radius R Tool radius R?
R2
Tool radius R2 for toroid cutters (only for graphical
representation of a machining operation with spherical or
toroid cutters)
Tool radius R2?
DL
Delta value for tool length L
Tool length oversize?
DR Delta value for tool radius R Tool radius oversize?
DR2 Delta value for tool radius R2 Tool radius oversize R2?
TL
Set tool lock (
TL: for Tool Locked Tool locked?
Yes = ENT / No = NO ENT
RT
Number of a replacement tool, if available (
RT: for
Replacement Tool; see also
TIME2).
Replacement tool?
TIME1 Maximum tool life in minutes. This function can vary
depending on the individual machine tool. Your machine
manual provides more information Maximum tool age?
TIME2
Maximum tool life in minutes during
TOOL CALL: If the
current tool life reaches or exceeds this value, the TNC
changes the tool during the next
TOOL CALL (see also
CUR_TIME).
Maximum tool age for TOOL
CALL?
CUR_TIME Current age of the tool in minutes: The TNC
automatically counts the current tool life (
CUR_TIME: for
CURrent TIME. A starting value can be entered for used
tools
Current tool age?
