Tables and overviews
21.1 Machine-specific user parameters
21
496
TNC 128 | User's Manual HEIDENHAIN Conversational Programming | 5/2014
Parameter settings
CfgToolMeasurement
M function for spindle orientation
-1: Spindle orientation directly via NC
0: Function inactive
1 to 999: Number of M function for spindle orientation
Probing routine
MultiDirections: Probing from more than one direction
SingleDirection: Probing from one direction
Probing direction for tool radius measurement
X_Positive, Y_Positive, X_Negative, Y_Negative (depending on tool axis)
Distance of tool lower edge to stylus upper edge
0.001 to 99.9999 [mm]: Offset of stylus to tool
Rapid traverse in probing cycle
10 to 300 000 [mm/min]: Rapid traverse in probing cycle
Probing feed rate with tool measurement
1 to 3000 [mm/min]: Probing feed rate with tool measurement
Calculation of probing feed rate
ConstantTolerance: Calculation of probing feed rate with constant tolerance
VariableTolerance: Calculation of probing feed rate with variable tolerance
ConstantFeed: Constant probing feed rate
Max. permissible rotation speed on the tool tip
1 to 129 [m/min]: Permissible rotation speed on mill circumference
Maximum permissible speed for tool measurement
0 to 1000 [1/min]: Maximum permissible speed
Maximum permissible measuring error during tool measurement
0.001 to 0.999 [mm]: First maximum permissible measuring error
Maximum permissible measuring error during tool measurement
0.001 to 0.999 [mm]: Second maximum permissible measuring error
