MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007 Page 93
Fuel Point
Figure 13-2: Individual Parameters Submenu
***FPR Individual Parameters ***
# ICR Ring: 1 2 3 4 5 6 7 8
- --- ---------------------------------------------
1 12 PO1 PO2 PO3 PO4 PO5 PO6 PO7 PO8
Enter reader number to modify or q to quit:
1 Enter the reader number to modify or q to quit: Enter the Fuel Point reader number that
you need to modify.
2 Associated ICR []: To which island card reader do the error messages go. The default is zero.
3 Ring #1 goes with device [PO1]: Enter the type of device to be activated by this ring. You
must specify what type of device is being controlled by each ring. Enter P# or just # for the
ring to activate the pump #; R# for the ring to activate the pump # as a gate; or G# for the ring
to open the gate.
Available Hour/Odometer Settings
The following table lists the allowable miles per gallon/hours per gallon combinations. The
first section lists the different vehicle module combinations. The second section (XPG) shows
the allowable calculation options for receipt printing. XPG represents unit per gallon.
Vehicle Module XPG (Unit/Gallon)
Meter 1 Meter 2 Meter 1 Meter 2
Odometer Hour MPG HPG
Odometer Odometer MPG -------
Hour Odometer HPG MPG
Hour Hour HPG -------
Odometer ------- MPG -------
Hour ------- HPG -------
For example, with a dual input vehicle module where meter 1 is odometer and meter 2 is hours
per gallon, the default XPG calculation will display Miles per Gallon on the receipt. The use
meter 2 option will display Hours per Gallon on the receipt.
Note: The hour meter reading is stored in the aux entry field of the transaction. If using the
aux entry for different data, set Global parameters to record hours in Router 1 or
Router 2 field. In this case, you cannot do hours per gallon calculations.
