Pump Configuration
Items to Configure
The items you can configure in the PCU submenu are as follows:
• Location Number: The number of this PCU. PCUs are numbered 1 through 32. (The
example below shows location numbers 1-11.)
• PCU Driver Type: The driver type of the PCU you are adding, by type number. Note that
these four drivers are selected by number, but are displayed on submenu 2 by their names.
The types available are:
1 Mechanical PCU. Use this if you have mechanical pumps assigned to a Gasboy PCU. It
has four slots available.
2 Electronic PCU. Use this if you have Gasboy electronic pumps or other makes, such as
Gilbarco, with a CFN interface. It has two slots available.
3 Tokheim PCU. Use this if you have Tokheim electronic pumps. There is one slot
available.
4 Special PCU. If you have the standard release of the Site Controller II software, then
use this PCU for Dresser-Wayne pumps. If you have a custom release software that
supports Unidynamics instead of Wayne, then use this PCU for Unidynamics pumps.
There is one slot available.
• Slot Assignment: The program will ask which pump number to assign to each available
slot for the PCU. If you specify a pump that is already assigned to a different PCU, it will
be reassigned.
Figure 3-2 is an example of a PCU configuration; in the two numbers separated by a
colon, the left number is the slot number, and the right number is the pump number.
Figure 3-2: Example of PCU Configuration
1. Mechanical PCU 1:1 2:2 3:3 4:4
2. Special PCU 1:5
3. Mechanical PCU 2:8 3:9
4. Tokheim PCU 1:11
5. Tokheim PCU 1:12
6. Tokheim PCU
7. Tokheim PCU
8. Tokheim PCU
9. Mechanical PCU 1:17
10. Tokheim PCU 1:13
11. Electronic PCU 1:14
12. Mechanical PCU
