Pump Configuration
Page 32 MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007
Add Pump Types
Submenu 3 allows you to add a new pump type, or to modify an existing pump type.
You will not need to add a new pump type unless you wish to use a pump that is not
compatible with any of the existing pump types. The pump type you add must be able to
interface with an existing driver (see below). When you add a new pump type, the program
will automatically assign it to the first free type number.
You should not change an existing pump type unless instructed to do so by your service
representative.
The submenu shows the pump name, the driver type (by number, in parentheses), and the
options (by number) for that pump type. You can add the following items in the pump type
submenu:
• Pump Name: The name of this type of pump. This is usually the manufacturer or model
name. Some pump types, such as car wash, are not really pumps.
• Driver Type: The type of driver this pump type uses. The following drivers are available:
1 Gasboy PCU. Use this with mechanical pumps.
2 Gasboy Electronic. Use this with Gasboy electronic pumps and MPDs and with
Gilbarco electronic pumps and MPDs.
3 Tokheim. Use this with Tokheim pumps and MMDs.
4 Special PCU. Use this with Wayne electronic or Unidynamics Series 90 electronic
counters and Model 20 OMC controller. (The special driver cannot be used with both
Wayne and Unidynamics pumps on the same Site Controller at the same time.)
• Options: The options for this pump type. You can add options, and if the pump type is
already shown, you can subtract options. To add options precede the option number with a
plus (+); to subtract options precede the option number with a minus (-). You can add and
subtract more than one option at a time. For example, +2-10 adds option 2 and subtracts
option 10. The following options are available:
1 Pump is a multi-product dispenser.
2 Pump always needs switch detect (off-hook) to activate.
3 Pump has a cash-credit select button. (Customer can choose cash or credit payment at
the pump.)
4 Site Controller can activate the pump without knowing the price or hose (for some
MPDs).
5 Site Controller cannot choose the hose number or price (for some MPDs).
6 Site Controller cannot get the dollar amount or volume during pumping.
7 Pump can't do switch detect or pulser time-outs (time-outs must be done by the driver).
