MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007 Page 65
Gate Configuration
9 – Gate Configuration
Use the disk-based configuration program GATE to see the configuration submenus for gates,
gate controllers, and car wash information. The system can have up to eight gates and eight
gate controllers. Each gate controller can have up to four gates connected to it.
Gate controllers can be used to control various types of gates and car washes. The gate
controller may have an alphanumeric display, or it may have no display.
Gate Submenus
The following is a list of the submenus currently available for the gate and gate controllers.
• “Gasboy Gates” on page 65
• “Gasboy Gate Controllers” on page 66
• “Unitec Wash Parameters” on page 69
• “Unitec Wash Types” on page 69
• “Unitec Wash Discounts” on page 71
Gasboy Gates
Enter the command GATE to see the gate configuration submenu, then select submenu 1 to
configure gates.
The gate submenu always shows eight gates ( Figure 9-1 ), even if there are fewer than eight
gates in the system. You can ignore any gates that are not configured in your system.
Figure 9-1: Gasboy Gate Submenus
# Prod Type Timeout
1 0 1 5
2 0 1 5
3 0 1 5
4 0 1 5
5 0 1 5
6 0 1 5
7 0 1 5
8 0 1 5
------------------------------------------------------------------
Enter number of gate to modify or q to quit:
