Island Card Reader Configuration
Displayed Messages
Some steps (13-21) display product or price information. Normally this is displayed at the end
of the message. To have this displayed somewhere else in the message, put an @ where you
want it to appear in your message.
For example, the default product name message (type 16) is just the name of the product
selected.
• If you type PRODUCT IS in response to the message prompt, the new message will be
what you typed followed by the product name.
• If you type @ SELECTED, the new message will be the product name followed by
Selected.
Any two messages for steps 3 through 21 can be displayed at the same time. To do this,
specify that the first message be displayed for 0 seconds. Put a caret (^) before the second
message and specify that it be displayed for as long as you want the entire message to be
displayed.
For example, to display the pump selected and amount approved messages together:
• Specify that the pump selected message (step type 14) be displayed for 0 seconds.
• For the step immediately following, specify that the amount approved message (step type
14) be displayed for the time you want the entire message to be displayed.
• Put a caret before the amount approved message.
• The ICR will display pump selected and amount approved together.
ICR Steps
Note: The first step in the ICR program must be either Insert Card or Select Pump.
1
Insert card: Insert card is the first step in the ICR program.
Most sites place this step first simply because that is the usual position for it at most other
sites, and so customers are used to inserting their cards first. However, if you place Insert Card
after Select Pump you will reduce the slight chance that confusion between ICR control or
console control of a pump might assign the wrong pump to the wrong card.
The default message is INSERT CARD.
2
Select pump: The Select Pump step should be placed before the Verify Card step. This lets the
Site Controller know exactly how much the maximum dollar amount will be for the
transaction, based on that pump's price and fill limit. See your Gasboy Representative if you
require a different setup.
This step must be included even on island card readers in pumps. Every reader configuration
must have a “select pump” program step prior to the “activate pump” step. Failure to include
the select pump step will cause warnings about unassigned transactions, with pumps becoming
disabled after the transaction.
The default message is SELECT PUMP NUMBER.
