Gate Configuration
Page 66 MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007
To modify the configuration of a gate once you are in the gate configuration submenu, proceed
as follows:
1
Enter the number of the gate you want to modify.
2
The program will prompt for the product to charge and show the current product in brackets.
Enter the product number of the product to charge a gate opening against. This is the product
number entered into the Site Controller with the LOAD PRODUCT command. For example, if
the gate is a car wash, the product entered here should be the car wash product; another
example is an oil vending machine.
If a gate opening should not be charged against a product (which will probably be the case),
enter a 0. To use the current product, just press Enter.
3
The program will then prompt for the type of gate and show the current gate type in brackets.
Gate types are:
• Open gate until time-out. The gate stays open until the time-out (specified in the next
item) is reached.
• Open gate until high-to-low voltage input or time-out. The gate stays open until a high-to-
low input is received or until the time-out is reached.
• Open gate until low-to-high voltage input or time-out. The gate stays open until a low-to-
high input is received or until the time-out is reached.
Enter the gate type. To use the current gate type, just press Enter.
4
The program will then prompt for the time-out and show the current time-out in brackets.
Enter the time in seconds that the gate is to stay open. If you specified gate type 2 or 3 above,
the gate will stay open until it receives the specified input or until the time-out is reached,
whichever is shorter.
To use the current time-out, just press Enter.
Gasboy Gate Controllers
Enter the command GATE to see the gate configuration submenu, then select submenu 2 to
configure gate controllers. The submenu always shows eight gate controllers (
), even if there are fewer than eight in the system. You can ignore any gate controllers
that are not configured in your system.
