Table Sizes
Page 42 MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007
20 Allocation Table: Stores allocation totalizers.
Each allocation totalizer takes one entry. Each allocation entry takes 10 bytes.
21 Sign-on Table: Stores user numbers and sign-on codes and permission levels.
Each user takes one entry. Each user entry takes 190 bytes. The maximum number of entries is
100.
22 Cron Table: Stores cron entries entered by LOAD CRON.
Each cron entry takes one entry. Each cron entry takes 54 bytes. The maximum number of
entries is 100.
23 TIP: Number of entries to allocate for table. Minimum number of entries is 40; maximum
number of entries is 150.
24 Diagnostics Table: Keeps a record of all the errors that occur for every device at the site since
the last time the diagnostics were reset. The current diagnostics can be printed with the Site
Controller command PRINT DIAGNOSTICS. They can be reset with the Site Controller
command RESET DIAGNOSTICS.
The number of entries in the diagnostics table should be equal to or greater than the total
number of gate controllers, PCUs, gauges, pumps, consoles, island card readers, and receipt
printers, plus one for the Site Controller.
Each device takes one entry. Each diagnostics entry takes 38 bytes. The minimum number of
entries is 20, and the maximum number of entries is 200.
25 Monitor Table: This table stores system monitor messages so that they may be viewed with
the PRINT MONITOR command. The number of entries determines the number of messages
that are stored. Storage is first in, first out.
Each entry takes 84 bytes.
26 Journal Table: This table stores information about merchandise items from transactions until
that information is logged or printed on a receipt.
Each entry takes 54 bytes. If used, the minimum number of entries is 0. The maximum number
of entries is 1,000.
27 Tax Table: This is the tax table set up by the TAX disk-based command. Some sites do not
need the TAX program, so they do not need this table.
The Site Controller offers two methods of computing taxes: percentage with rounding or table
look-up. The table look-up method should be used only when you are required by law to use a
paper table for computing taxes and that table is not equivalent to any percentage and rounding
boundary.
Each entry in the paper table uses one entry in the tax table. Each tax table entry uses 6 bytes.
The minimum number of entries is 9, and the maximum number of entries is 200.
