Island Card Reader Configuration
Page 56 MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007
The program steps types are:
1 = Insert card* 12 = Remove card
2 = Select pump* 13 = Display text
3 = Enter PIN 14 = Display pump selected
4 = Enter amount 15 = Display amount authorized
5 = Enter account 16 = Display product name
6 = Enter auxiliary number 17 = Display product price
7 = Enter odometer 18 = Display allocation balance
8 = Want car wash or merchandise 19 = Display pump ready
9 = Verify card 20 = Display product and price
10 = Activate pump 21 = Display card holder’s name
11 = Print receipt
* Either of these 2 steps must be first in the ICR program.
Submenu 1 lists the steps in the ICR program. For each step it shows the following:
• The step number (#).
• The step type (Ty). In the 21 steps listed above, the numbers 1-21 are the step-type
numbers that you use to enter a step into the Reader program.
• The number of seconds the message is displayed or the number of digits to be entered
(S/D).
• The message to be displayed (DISPLAY).
• The subsequent message displayed after the first digit of a field is entered (WHILE
ENTERING). The display lasts until the customer presses Enter or auto entry takes over
or trans time-out.
• The options, if any, in effect for that step (OPTIONS).
Options for ICR Program Steps
Several of the ICR program steps have options available. The options are auto entry, mask
data display, and optional entry.
Auto entry is useful for steps that require the customer to enter a fixed number of digits, such
as the enter PIN step.
With auto entry, when a customer enters the number of digits indicated for that step, the
program continues automatically. Without auto entry, the customer must manually press
Enter to get the program to continue.
The mask data display option is normally used for the enter PIN step. If the mask data display
option is selected, when the user enters numbers from the keypad, asterisks are displayed
instead of the numbers for each digit entered.
A few steps allow optional entry. The enter odometer (type 7), enter PIN (type 3), enter
amount (type 4), enter account (type 5), and enter auxiliary number (type 6) steps can be
optional. If these steps are optional, they will be requested only if required by the restriction
code on the club card or by the system parameters.
