MDE-4316C CFN Series CFN III Configuration Manual for Windows NT® · April 2007 Page 67
Gate Configuration
Figure 9-2: Gasboy Gate Controller Configuration Submenu
# Display Broadcast Gates
1 No No 1=1 2=2 3=3 4=4
2 No No
3 No No
4 No No
5 No No
6 No No
7 No No
8 No No
------------------------------------------------------------------
Enter number of gate controller to modify or q to quit:
To modify the configuration of a gate once you are in the gate configuration submenu:
1 Enter the number of the gate reader you want to modify.
2 The submenu will display the prompt Display. Enter a y if the gate controller has a display, or
an n if the gate controller does not have a display. If you are not changing this item, press
Enter.
3 Then the submenu will display the prompt Broadcast message. Enter a y if broadcast messages
should be displayed on the gate controller display, or an n if they should not be displayed.
The gate controller must have an alphanumeric display if it is to display the broadcast
messages.
4 The submenu will then display the prompt Gate for output 1. (An output is the control signal
put out by the gate controller, usually through a relay. It is, in effect, the address of a gate.)
Each gate controller has four outputs, and each output can control one gate. Output 1 usually
controls gate 1, but you do not have to match the numbers that way; output 1 can just as easily
control gate 2, 3, or 4.
Enter the number of the gate connected to the first output of the gate controller. The submenu
will prompt for the numbers of the gates connected to the other outputs. If there is no gate
connected to an output, press Enter for that prompt.
The submenu display shows the output and the number of the gate separated by an equals sign
(=). For example, if gate 1 is connected to output 1, it shows 1=1.
