Delta Electronics AC Motor Drive VFD-G User Manual
Page 96
Chapter 4 Parameters|
Revision July 2008, EG03, SW V1.06
4-45
04 - 26
1st Analog Input Frequency Gain
Unit: 0.01
04 - 27
2nd Analog Input Frequency Gain
Unit: 0.01
04 - 28
3rd Analog Input Frequency Gain
Unit: 0.01
04 - 29
4th Analog Input Frequency Gain
Unit: 0.01
Settings
0.00~160.00Hz
Factory Setting: 0.00
These parameters divide output frequency into several sections. (Refer to Pr.04-22).
04 - 30
1st Output Frequency Gain
Unit: 0.1
04 - 31
2nd Output Frequency Gain
Unit: 0.1
04 - 32
3rd Output Frequency Gain
Unit: 0.1
Settings
0.0~200.0%
Factory Setting: 100.0
These parameters set output frequency gain. We can select the functions of 21st to 23rd via
multi-function terminal. When the multi-function terminal is active, output frequency multiplies a
gain, i.e. output frequency H=F*(Pr.04-30/04-31/04-32).
