Chapter 4 Parameters|
Revision July 2008, EG03, SW V1.06 4-9
Parameter Functions Settings
Factory
Setting
Customer
04-14 2nd AI1 Gain 0.0~100.0% 100.0
04-15 3rd AI1 Gain 0.0~100.0% 100.0
04-16 4th AI1 Gain 0.0~100.0% 100.0
04-17 5th AI1 Gain 0.0~100.0% 100.0
04-18 1st AI2 Gain 0.0~100.0% 100.0
04-19 2nd AI2 Gain 0.0~100.0% 100.0
04-20 3rd AI2 Gain 0.0~100.0% 100.0
04-21 4th AI2 Gain 0.0~100.0% 100.0
04-22 5th AI2 Gain 0.0~100.0% 100.0
04-23 Analog Input Delay
AI1
0.00~10.00 Sec 0.50
04-24 Analog Input Delay
AI2
0.00~10.00 Sec 0.50
04-25 Summation of
External Frequency
Sources
00: Disabled
01:AI1*( AI1 Gain) + AI2*( AI2 Gain)
02:AI1*( AI1 Gain) - AI2*( AI2 Gain)
03: AI1*( AI1 Gain) * AI2 *( AI2 Gain)
04: Reserved
05: Communication master
frequency+AI1*( AI1 Gain)
06: Communication master
frequency+AI2*( AI2 Gain)
07: Max (AI1*( AI1 Gain), AI2*( AI2 Gain))
00
04-26 1st AI Frequency
Gain 0.00: Disabled
0.01~160.00 Hz 0.00
04-27 2nd AI Frequency
Gain 0.00: Disabled
0.01~160.00 Hz 0.00
04-28 3rd AI Frequency
Gain 0.00: Disabled
0.01~160.00 Hz 0.00
04-29 4th AI Frequency
Gain
0.00: Disabled
0.01~160.00 Hz 0.00
04-30 1st Out Frequency
Gain 0.0 to 200.0% 100.0
04-31 2nd Out Frequency
Gain 0.0 to 200.0% 100.0
04-32 3rd Out Frequency
Gain 0.0 to 200.0% 100.0
