Delta Electronics AC Motor Drive VFD-G User Manual
Page 102
Chapter 4 Parameters|
Revision July 2008, EG03, SW V1.06
4-51
05-05
Frequency
Master Speed
05-00
05-01
05-02
05-03
05-04
05-06
05-07
05-08
05-09
05-10
05-11
05-12
05-13
05-14
01-19
JOG Freq.
2 3 4 5 6 7 8 9 1011 12 131415
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
Run Signal
2nd step speed Multi-function Terminal
Pr.04-00 to Pr.04-07 (MI1 to MI8 2)
1st step speed Multi-function Terminal
Pr.04-00 to Pr.04-07
(MI1 to MI8 1)
3rd step speed Multi-function Terminal
Pr.04-00 to Pr.04-07 (MI1 to MI8 3)
4th step speed Multi-function Terminal
Pr.04-00 to Pr.04-07 (MI1 to MI8 4)
Jog Freq.
Multi-Step Speed via External Terminals
05 - 32
Time Unit Settings
Factory Setting: 00
Settings
00
1
Sec
01
0.1
Sec
This parameter determines the time unit for Pr.05-17~Pr.05-31.
