Chapter 4 Parameters|
4-10 Revision July 2008, EG03, SW V1.06
Group 5 Multi-step Speed Parameters
Parameter Functions Settings
Factory
Setting
Customer
05-00 1st Step Speed
Frequency
0.00~160.00 Hz 0.00
05-01 2nd Step Speed
Frequency
0.00~160.00 Hz 0.00
05-02 3rd Step Speed
Frequency
0.00~160.00 Hz 0.00
05-03 4th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-04 5th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-05 6th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-06 7th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-07 8th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-08 9th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-09 10th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-10 11th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-11 12th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-12 13th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-13 14th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-14 15th Step Speed
Frequency
0.00~160.00 Hz 0.00
05-15 PLC Mode 00: Disable PLC Operation
01: Execute one program cycle
02: Continuously execute program cycles
03: Execute one program cycle step by step
04: Continuously execute program cycles
step by step
00
05-16 PLC Forward/ Reverse
Motion
00 to 32767 (00: FWD 01: REV) 00
05-17 Time Duration Step 1 0.0 to 65500 Sec / 0.0~6550.0 Sec 0.0
05-18 Time Duration Step 2 0.0 to 65500 Sec / 0.0~6550.0 Sec 0.0
05-19 Time Duration Step 3 0.0 to 65500 Sec / 0.0~6550.0 Sec 0.0
