Appendix B Accessories|
Revision July 2008, EG03, SW V1.06
B-5
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I（A）
Bussmann P/N
VFD055F43B-G 14 13 30 JJS-30
VFD075F43B-G 19 18 40 JJS-40
VFD110F43A-G 25 24 50 JJS-50
VFD150F43A-G 32 32 60 JJS-60
VFD185F43A-G 39 38 75 JJS-70
VFD220F43A-G 49 45 100 JJS-100
VFD300F43A-G 60 60 125 JJS-125
VFD370F43A-G 63 73 150 JJS-150
VFD450F43A-G 90 91 175 JJS-175
VFD550F43A-G 130 110 250 JJS-250
VFD750F43A-G 160 150 300 JJS-300
VFD900F43C-G 160 180 300 JJS-300
VFD1100F43C-G 200 220 400 JJS-400
VFD1320F43A-G 240 260 500 JJS-500
VFD1600F43A-G 300 310 600 JJS-600
VFD1850F43A-G 380 370 600 JJS-600
VFD2200F43A-G 400 460 800 JJS-800
